Metri-Pack 280 connector kit 2-pin — complete

Complete kit for one watertight 2-pin Metri-Pack 280 connection: both housings, terminals, seals and locking — including a spare terminal of each type and 2 spare seals, in case a crimp goes wrong. Pick the wire size — terminals and seals are matched per option. No more sourcing loose parts.

Contents:

• 1× connector 2-pin male black (15300002)
• 1× connector 2-pin female black (15300027)
• 3× male + 3× female terminals in the chosen size (2 + 1 spare each) (2.0–3.0: 12129497/12129493 · 3.0: 12048254/12077413)
• 6× matching cable seals (4 + 2 spares) (gray / blue — by option and insulation OD)
• 1× secondary lock (TPA) blue (15300014)

• Series: Metri-Pack 280
• Number of pins: 2
• Wire size: 2.0–3.0 mm² or 3.0 mm² by option (14–12 AWG)
• Current: max. 30 A
• Sealing: fully watertight
• Temperature: -40 to +125 °C
